- - Tốc độ in 127 mm/giây. In nhanh và sắc nét
- - In hình ảnh, logo hoặc mã vạch sản phẩm
- - Hỗ trợ in tiếng Việt; Hỗ trợ hầu hết các chuẩn Barcode
Thông số kỹ thuật
Printing method | Thermal line printing | |
Resolution | 203dpi (8dots/mm) | |
Print width | 20mm ~ 82mm | |
Print speed | 127mm/sec. (Max.); 101mm/sec. (Min.) | |
Memory | DRAM: 2M ; FLASH: 2M | |
Print head temperature sensor | Thermal sensitive resistance | |
Print head position sensor | Microswitch | |
Black mark sensor | Photoeletric sensor | |
Interface | USB + RS-232 + LAN | |
Barcode font&Graphics | Barcode | CODE128, EAN128, ITF, CODE39, CODE93, EAN13,EAN13+2, EAN13+5, EAN8, EAN8+2, EAN8+5,CODABAR, POSTNET, UPC-A, UPCA+2, UPCA+5,UPC-E, UPCE+2, UPC-E+5, CPOST, MSI, MSIC,PLESSEY, ITF14, EAN14 |
Internal font | FONT 0 to FONT 8; Simplified Chinese,Traditional Chinese, Korean | |
Enlargement & rotation | 1to10 times enlargement in both directions; 0°, 90°, 270°, 360°rotation | |
Graphics | Black and white PCX and BMP files can be downloaded into FLASH and DRAM | |
Media | Media type | Continous,sticker,fan-fold,etc. |
Media width | 16mm ~ 82mm | |
Media diameter | Max.85mm | |
Media core diameter | Min.25mm | |
Paper off type | Tear off & peel off | |
Power | Imput | 24VDC, 2.5A |
Environment condition | Work | 5 ~ 45°C, 20~80%RH |
Storage | -40~55°C, ≤93%RH (40°C) | |
Physical dimension | Dimension | 220 (D) x 148 (W) x 150 (H) mm |
Weight | 1.5kg | |
